Introduction to Pressure

The Push and the Point

Force is a push or a pull. But the effect of that force can change dramatically depending on how it's applied. Think about pushing a thumbtack into a corkboard. You push on the flat, wide head with your thumb, and the sharp, tiny point slides easily into the board. You're applying the same force to both ends of the tack, so why does one end barely leave a mark on your thumb while the other sinks deep into the cork? The answer is pressure.

Pressure is the amount of force concentrated over a certain area.

The force from your thumb is spread out over the large area of the tack's head, creating low pressure. That same force is concentrated on the tiny, sharp point, creating immense pressure – enough to pierce the board. This relationship is captured in a simple formula.

P=FAP = \frac{F}{A}

Here, PP is pressure, FF is the force applied perpendicular to the surface, and AA is the area over which the force is spread. This shows that pressure is directly proportional to force (more force, more pressure) and inversely proportional to area (more area, less pressure). This is why a person wearing snowshoes can walk on top of deep snow while someone in regular boots sinks. The snowshoes spread the person's weight (the force) over a much larger area, reducing the pressure on the snow.

Lesson image

Units of Pressure

Since pressure is a fundamental concept in science and engineering, it has several different units of measurement. The standard international (SI) unit for pressure is the Pascal, named after the French physicist Blaise Pascal.

Pascal

noun

The SI unit of pressure, equal to one newton of force per square meter of area (N/m²).

One Pascal is a very small amount of pressure, so we often use kilopascals (kPa), which is 1,000 Pascals, or even megapascals (MPa), which is one million Pascals. You'll also encounter other units in different contexts. For example, tire pressure is often measured in pounds per square inch (psi), while weather reports might use atmospheres (atm) or millibars (mbar).

UnitSymbolEquivalent in Pascals (approx.)
PascalPa1 Pa
Atmosphereatm101,325 Pa
Barbar100,000 Pa
Pound per square inchpsi6,895 Pa

Focusing the Force

Let's bring it back to the kitchen. A chef's knife is most effective when it's sharp. Why? A sharp edge has a very small surface area. When the chef pushes down, the force is concentrated on that tiny area, creating extremely high pressure. This high pressure is what allows the knife to slice cleanly through a tomato.

A dull knife has a wider, more rounded edge, meaning a larger surface area. To cut that same tomato, the chef would need to apply a much greater force to achieve the same cutting pressure. It’s not about pushing harder; it's about applying force more efficiently by reducing the area.

The key relationship is simple: To increase pressure, you can either increase the force or decrease the area it's applied to.

This principle applies everywhere, from the way a hydraulic press works to the design of a needle. Now, let's test your understanding of these core concepts.

Quiz Questions 1/5

Which of the following statements best describes the relationship between pressure, force, and area?

Quiz Questions 2/5

Why is a sharp knife more effective at cutting than a dull knife?
