Working with drawings that lack proper block definitions can be tedious. You've likely spent hours manually replacing repetitive geometry. AutoCAD's Smart Blocks features use machine learning to automate this process, turning manual cleanup into a task that takes seconds.

The core of this is the Search and Convert tool. It scans your drawing, identifies identical sets of geometry, and gives you the option to convert them into block instances instantly. This not only cleans up the drawing but also significantly reduces file size and makes future edits much simpler. Imagine tidying up a floor plan with dozens of identical chairs drawn with individual lines, all with a single command.

A related and powerful command is BCONVERT. It works alongside the Object Detection feature. First, you use Object Detection to find all instances of a specific geometry. Once they're all selected, BCONVERT converts them into a block in one step. It's a more direct way to achieve a similar result to Search and Convert.

The AI assistance doesn't stop there. Once you've defined a block, AutoCAD will start suggesting placement locations as you insert it. By analyzing the existing geometry in your drawing, it predicts where you're likely to place the next instance of that block. For example, if you place one desk against a wall, it might suggest similar positions along that same wall, complete with alignment and spacing.

You'll often inherit drawings from other sources that are messy, old, or were created without adhering to block standards. These 'legacy' files are functional but inefficient. The Object Detection Tech Preview is designed specifically for this scenario.

This tool helps you select all objects within a drawing that are geometrically similar to one you've picked. Think of it as a highly advanced 'Select Similar' command that understands shapes, not just properties. You can select a hand-drawn door symbol, and the Object Detection tool will find every other instance of that same door geometry, even if they aren't blocks. This is the first step in a powerful cleanup workflow.

After using Object Detection to gather all the similar geometry, you can then use a command like BLOCK or the previously mentioned BCONVERT to transform them all into a single, unified block definition. This pairing of features allows you to rapidly impose order and standards on even the most chaotic legacy drawings.

Traditionally, the Hatch command required a closed, sealed boundary to work. Any small gap would prevent the hatch from being created. AutoCAD now allows you to create a hatch pattern along a specified path, using either an open or closed polyline.

Instead of selecting a point inside an area, you can now use the 'Path' option within the HATCH command. You simply select a polyline, and the hatch pattern is generated along its length with a specified width. This is perfect for representing things like roads, walls, or pipes without needing to draw extra parallel lines just to create a boundary.

The width of the hatch path is controlled by a system variable called HPPATHWIDTH. You can set this value before creating your hatch to define how wide the pattern should be. Once created, the hatch and its path behave as a single object, and you can easily edit the path's shape using its grips, with the hatch pattern updating automatically.

Now, let's test what you've learned about these AI-powered drafting tools.
