You've mastered drawing lines, arcs, and circles. Now it's time to make your drawings intelligent. Instead of creating static objects, you can define relationships between them. This is the core idea behind parametric drafting—a method where your geometry automatically adjusts based on rules you set. When one part of the design changes, everything connected to it updates logically.

Geometric constraints are the rules that govern the relationships between 2D objects. They don't define size or position; instead, they lock in how objects behave relative to one another. Think of them as enforceable instructions: "these two lines must always be parallel," or "this circle must always share a center with that arc."

Common geometric constraints include:

• Coincident: Forces two points to stay connected, or a point to lie on an object.
• Perpendicular: Makes two lines maintain a 90-degree angle.
• Tangent: Ensures two curves touch at a single point without crossing.
• Concentric: Forces circles, arcs, or ellipses to share the same center point.
• Symmetric: Makes two objects mirror each other across a specified line.

Applying these constraints transforms a simple drawing into a flexible model. If you adjust the angle of one line in a perpendicular relationship, the other automatically pivots to maintain the 90-degree angle.

After establishing geometric rules, you use dimensional constraints to control size and distance. These assign specific values to your geometry, such as length, angle, or radius. For instance, you can set a line's length to exactly 150mm or the angle between two lines to 45 degrees.

When a dimensional constraint is applied, it works in tandem with the geometric constraints. If you have a rectangle with perpendicular and parallel constraints, you only need to add two dimensional constraints—one for length and one for width—to fully define its shape. Changing the length dimension will stretch or shrink the rectangle while all four corners remain at 90 degrees.

As drawings become more detailed, selecting the right object can feel like a clumsy game of trial and error. Complex architectural plans or mechanical assemblies often have dozens of overlapping lines and components. This is where advanced selection tools become essential for efficiency and accuracy.

The Quick Select tool, often activated with the command QSELECT, acts like a search filter for your drawing. Instead of manually picking objects, you define a set of criteria to find exactly what you need. You can select all objects of a certain type (e.g., all circles), all objects on a specific layer, or all objects with a particular property (e.g., all red lines). This is incredibly powerful for making bulk changes, like modifying all the bolts of a certain size in an assembly without affecting anything else.

Sometimes objects are stacked directly on top of each other, making it impossible to select one underneath with a simple click. Selection Cycling solves this problem. When enabled, clicking on overlapping objects brings up a small list box showing every object under your cursor. You can then simply click the desired object from the list. It's a simple toggle that eliminates the frustrating process of zooming in or hiding objects just to make a selection.

Finally, combining Object Snap Tracking with Point Filters allows for ultimate precision without creating extra construction lines. Object Snap Tracking lets you infer new points from existing snap locations, like tracking horizontally from an endpoint and vertically from a midpoint to find their intersection in empty space. Point filters take this a step further by letting you "borrow" coordinate values from different points. For example, you can start a line by specifying its X coordinate from one endpoint and its Y coordinate from another, precisely placing the new point without any direct reference.

By mastering these advanced controls, you move from simply drawing to designing an intelligent and responsive system. Your work becomes faster, more accurate, and far easier to modify.
