Getting Started

First Steps with EDIUS

Getting started with EDIUS begins with installation. After downloading the software, run the installer and follow the on-screen instructions. You'll need a serial number to activate the program, which you typically receive upon purchase. The activation process links the software to your machine and unlocks its full capabilities.

Once installed and activated, the first thing you'll do is create a new project. A dialog box will appear asking you to choose a project preset. These presets contain standard settings for resolution and frame rate, like 1920x1080 at 29.97 frames per second. Don't worry too much about picking the perfect one right away; just choose one that closely matches the footage you plan to edit.

The EDIUS Workspace

When you open a project, you'll see the main EDIUS workspace. It might look complex, but it's organized into a few key areas. The layout is fully customizable, so you can rearrange windows to fit your workflow, but most editors start with a standard setup.

Here’s a breakdown of the primary windows:

  • Bin Window: This is your media library. You'll import all your video clips, audio files, and images here. It works just like a folder system on your computer, allowing you to organize assets for your project.
  • Preview Window: This area is split into two monitors. The Player (left) is for viewing your original, unedited source clips from the Bin. The Recorder (right) shows the edited sequence from your Timeline.
  • Timeline: This is where the magic happens. You'll drag clips from the Bin onto the Timeline to build your video. The Timeline is a visual representation of your project from start to finish, with different tracks for video and audio.

Setting Up for Success

Before you start editing, it's wise to check a few key project settings. You can access these through the settings menu. The most important ones relate to your video format, such as resolution (e.g., 1920x1080 or 3840x2160) and frame rate (e.g., 24, 30, or 60 fps). Matching these to your primary source footage ensures the best performance and quality.

A good habit is to create project presets for cameras you frequently use. This saves you from having to configure settings every time you start a new project.

EDIUS also allows for extensive workspace customization. You can click and drag the edge of any window to resize it. You can also undock windows and move them to a second monitor. To save a layout you like, go to the "View" menu and find the option to save the current layout. This lets you create different workspaces for different tasks, like one for organizing media and another for fine-tuning edits.

Supported File Formats

One of the strengths of EDIUS is its ability to handle a wide variety of video formats without needing to convert them first. This is often called "native editing," and it saves a lot of time. EDIUS supports most file types from consumer cameras, professional camcorders, and cinema cameras.

Camera TypeCommon FormatSupported in EDIUS?
Mirrorless/DSLRMP4 (H.264/H.265)Yes
Professional CamcorderXAVC, AVC-IntraYes
Apple DevicesMOV (ProRes)Yes
Cinema CameraCinema DNG, RAWYes (with options)

This means you can often mix and match footage from different cameras directly on the same timeline. The software is built to handle these different formats in real-time, which makes the editing process much smoother.

Now that you're familiar with the basic setup, let's test your knowledge.

Quiz Questions 1/5

What is the primary function of the Bin window in EDIUS?

Quiz Questions 2/5

In the standard EDIUS layout, the Preview Window is split into two monitors. Which monitor is used to view the edited sequence from your Timeline?

You've taken the first steps to understanding the EDIUS environment. With this foundation, you're ready to start importing media and building your first sequence.
