Imagine watching a movie scene set in space. You want the blackness of space to be truly black, and the stars to be pinpricks of bright light. On many screens, this is a challenge. Traditional LCD screens have a backlight that's always on, shining through the pixels. Even when the pixels try to block the light to create black, some light still leaks through, turning deep blacks into a hazy gray.

Local dimming is a clever solution to this problem. Instead of a single, uniform backlight, the screen's lighting is divided into different zones. The TV or monitor can then independently control the brightness of each zone. If a part of the image is dark, the backlight in that zone can be dimmed or even turned off completely. If another part is bright, its backlight stays on at full power. This creates a much higher contrast between the darkest and brightest parts of the picture, making the image pop with more realism and depth.

Not all local dimming is created equal. The effectiveness depends heavily on how the LEDs that make up the backlight are arranged. There are two main approaches.

In an edge-lit display, the LEDs are placed along the edges of the screen, usually at the top and bottom or on the sides. They shine light inward, which is then spread across the back of the screen by a diffuser panel. The dimming zones are typically arranged in vertical or horizontal bands. This method allows for thinner and less expensive screens, but it's less precise. Since the light comes from the side, it's difficult to isolate small, specific areas, which can sometimes cause light to bleed into darker sections.

A more advanced and effective method is full-array local dimming. Here, hundreds or even thousands of LEDs are placed in a grid directly behind the entire screen. This allows the display to control the brightness of many small, precise zones. FALD provides far superior contrast and less light bleed because the light source is directly behind the part of the image it's illuminating. This results in deeper blacks and more impactful highlights.

More recent technologies like Mini-LED and Micro-LED are extensions of the full-array concept. They use even smaller and more numerous LEDs, offering thousands of dimming zones or, in the case of Micro-LED, control over every single pixel. This provides a level of contrast that rivals other screen technologies.

The primary benefit of local dimming is a dramatic improvement in picture quality. By making darks darker, the bright parts of the image appear even brighter and more vibrant.

Beyond a better picture, local dimming is also more energy-efficient. A screen doesn't need to waste power by keeping the entire backlight at full brightness all the time. By dimming or turning off unused sections, the display consumes less electricity.

However, the technology isn't perfect. A common side effect, especially on displays with fewer dimming zones, is called "blooming" or the "halo effect." This happens when light from a bright object on a dark background bleeds into the dark area, creating a soft glow or halo around it. This occurs because the dimming zone is larger than the bright object itself. More advanced systems with a greater number of zones minimize this issue, but it can still be a trade-off for the enhanced contrast.

Ready to check your understanding?

Local dimming is a key technology in modern TVs and monitors, pushing image quality forward by tackling one of the fundamental limitations of LCD screens. By intelligently controlling the backlight, it delivers deeper blacks, brighter highlights, and a more immersive viewing experience.
