Instead of burning fuel directly inside the main furnace, the Healy Unit 2 power plant uses a more specialized approach. Two large, multi-stage slagging combustors are mounted on the outside walls of the boiler. These units act as external furnaces, processing the coal and removing most of the ash before the hot gases ever enter the main boiler. This design significantly changes how the system manages heat and impurities.

Each combustor is a complex, three-part system designed for a specific sequence of operations. It begins in the precombustor, transitions to a high-temperature vortex, and ends by separating the liquid ash.

The process starts in the precombustor. Here, a stream of hot air mixes with finely ground coal, initiating the first stage of combustion in a fuel-rich environment. This initial burn is intentionally incomplete.

The partially burned fuel and hot gas then blast into the main slagging stage. This is the heart of the unit. More hot air is injected tangentially, creating a powerful cyclonic flow, much like a tornado. Temperatures here soar above 2,800°F (1,540°C), instantly melting the mineral impurities in the coal into a liquid slag.

Finally, the hot gas and molten slag enter the slag recovery section. The cyclone's centrifugal force slings the heavier liquid slag against the walls, where it drains down into a collection point. The now much cleaner hot gas, with up to 90% of its ash removed, exits the top of the combustor and is directed into the main boiler to generate steam. This separation is key to the entire design.

Operating at temperatures hot enough to melt steel requires sophisticated engineering. The combustor is built with tube-membrane walls, a design common in high-pressure boilers. This construction consists of a series of steel tubes welded together with steel strips (membranes) in between, creating a strong, continuous, and gas-tight wall.

High-pressure water constantly circulates through these tubes. This water-cooling system serves two purposes. First, it prevents the combustor walls from melting. Second, it chills the molten slag just enough to create a thin, protective, semi-solid layer on the wall's surface. This frozen slag layer insulates the metal from the extreme heat and corrosive environment of the core, allowing the liquid slag to flow smoothly down to the recovery section without eroding the combustor itself.

The cyclonic flow is the mechanism that separates the ash. By forcing the gas into a high-speed vortex, the combustor essentially becomes a centrifuge. The molten slag droplets, being much denser than the gas, are subjected to immense centrifugal forces and flung outwards. They collide with the water-cooled walls, stick to the semi-solid slag layer, and drain away.

This design presents a significant trade-off. By removing ash before the main furnace, it drastically reduces erosion and fouling of the boiler's heat-exchange tubes, improving reliability and thermal efficiency. However, it introduces the complexity of managing a continuous stream of molten rock at 2,800°F. The interface where the clean gas exits the combustor and enters the boiler is a critical zone, as is the slag tap at the bottom. In an Arctic environment like Healy, preventing this molten material from freezing and causing blockages is a major engineering challenge.

Now, let's test your understanding of this unique architecture.

By mastering the flow of fuel, air, and slag, this external combustion system achieves high efficiency while protecting the main boiler from the most damaging components of coal.
