Architectural Routing Patterns

The Smart Dispatcher

A single, powerful AI agent trying to do everything is like a brilliant chef forced to also wait tables, wash dishes, and manage the front desk. It's inefficient and expensive. A better approach is the router-specialist architecture, where one primary agent acts as a smart dispatcher, directing incoming tasks to the best-suited specialist agent.

This pattern creates a system that's faster, more cost-effective, and easier to manage. The "router" agent, typically a capable model like Claude 3.5 Sonnet, receives every request. Its only job is to analyze the user's intent and delegate the task to a downstream specialist. These specialists can be fine-tuned for specific functions: a nimble Haiku model for quick data extraction, a Sonnet for nuanced summarization, or a powerful Opus for complex code generation. This division of labor ensures you're always using the right tool for the job.

Choosing the Right Tool

The core logic of the router revolves around selecting the optimal model for the job. This decision is a trade-off between capability, speed, and cost. Using Opus for a simple classification task is like using a sledgehammer to crack a nut—it works, but it's overkill. Conversely, asking Haiku to design a multi-layered software architecture will lead to poor results.

ModelBest ForKey Characteristics
Claude 3 HaikuSimple, high-volume tasks (classification, extraction)Fastest, most affordable, lightweight
Claude 3.5 SonnetGeneral purpose, routing, complex summarizationBalanced speed, cost, and intelligence
Claude 3 OpusHighly complex reasoning, deep analysis, R&DMost powerful, highest cost, slower

A good router agent, usually powered by Sonnet, can analyze an incoming query and make a sophisticated judgment call. It weighs the user's intent against the known capabilities of the specialist agents and routes the request accordingly. This dynamic selection is what makes the architecture so efficient.

Crafting the Routing Logic

The router's effectiveness depends almost entirely on its instructions. You need to provide a clear and structured prompt that gives it the context needed to make the right call. This is where classification prompt engineering comes in. The goal is to create a prompt that forces the router to output a specific, predictable choice based on its analysis.

A robust router prompt should clearly define the available specialists, describe what each one does, and provide examples of requests they should handle. Using XML tags to structure this information helps Claude models process the rules with high accuracy.

<system_prompt>
You are a router agent. Your purpose is to classify the user's request and forward it to the correct specialist. You must respond with only the name of the appropriate specialist.

Here are the available specialists:

<specialist>
  <name>Email_Classifier</name>
  <description>Sorts incoming emails into one of three categories: Urgent, General, or Spam. Best for short text classification.</description>
  <model>Claude 3 Haiku</model>
</specialist>

<specialist>
  <name>Report_Summarizer</name>
  <description>Reads long financial documents or reports and provides a concise, multi-paragraph summary. Handles complex language and context.</description>
  <model>Claude 3.5 Sonnet</model>
</specialist>

<specialist>
  <name>Strategy_Generator</name>
  <description>Analyzes market data and business requirements to generate novel strategic plans. Requires deep, creative reasoning.</description>
  <model>Claude 3 Opus</model>
</specialist>

Analyze the user's request and respond with only the <name> of the correct specialist.
</system_prompt>

This structured approach makes far more reliable. The router isn't just guessing; it's performing a mapping exercise between the user's query and the explicit capabilities you've defined.

Deterministic vs. LLM-Based Routing

There are two main ways to implement the routing logic itself. The first is deterministic routing. This approach uses simple, rule-based logic, like keyword matching or regular expressions, to classify a request. For example, if a query contains the word "summary," it's automatically sent to the Report_Summarizer. This method is fast, predictable, and cheap, but it's also brittle. It can easily fail if the user's language doesn't match the predefined rules.

The second, more powerful method is —the approach we've been discussing. Here, a language model like Sonnet makes the decision. It's far more flexible and can understand nuance and context that rigid rules would miss. A user could say, "Can you give me the highlights of this PDF?" and the LLM router would correctly identify the intent as summarization, even though the word "summary" wasn't used.

For most sophisticated applications, a hybrid approach works best. Use deterministic routing for simple, clear-cut cases to save time and money, and fall back on an LLM-based router for more ambiguous or complex queries.

Quiz Questions 1/5

What is the primary function of the 'router' agent in a router-specialist AI architecture?

Quiz Questions 2/5

A user submits the prompt: 'I need a complex Python script to perform a multi-step data analysis.' In a well-designed router-specialist system, which type of model would be the most appropriate specialist for this task?
