You already know how to insert effects directly onto a channel strip. That's serial processing: the signal flows through one effect, then the next, then the next. But for a richer, more dynamic mix, we need to process in parallel. This means splitting your signal, processing one copy heavily, and then blending it back in with the original, dry signal.

The most common use for this is parallel compression, sometimes called New York Compression . Imagine you want a drum bus to feel huge and punchy. If you just slam it with a compressor, you'll crush its dynamics and lose all the snappy detail in the initial hits, known as transients. With parallel compression, you get the best of both worlds: the full, uncompressed punch of the original drums blended with a second, heavily compressed signal that adds body and sustain.

Here’s the basic routing:

1. Create a new Aux track. Let's call it "Parallel Comp."
2. On your source track (e.g., a drum bus), create a send to a new bus—say, Bus 1. Logic will automatically assign the input of your new Aux track to Bus 1.
3. Set the send level to 0 dB (unity gain) and make it "Pre-Fader." This ensures the level sent to your parallel track isn't affected by the main fader.
4. On the "Parallel Comp" Aux track, insert a compressor. Use extreme settings: a high ratio (10:1 or higher), fast attack, and fast release. Adjust the threshold to get a lot of gain reduction, maybe 10-20dB.
5. Now, bring the fader for the "Parallel Comp" track all the way down. With your source track playing, slowly raise the parallel track's fader to blend its signal into the mix. You'll hear the sound get thicker and more powerful. This same technique works wonders with parallel saturation or reverb.

You're likely used to grouping tracks with a Summing Stack, which routes the audio of several tracks to a single Aux track. This is great for processing a whole group of instruments together, like applying EQ to all your background vocals at once.

However, there's another, more flexible way to control groups: VCA Faders . A VCA Fader doesn't actually have any audio passing through it. Instead, it acts like a remote control for the faders of the tracks assigned to its group. When you move the VCA Fader, all the linked faders move proportionally.

So why use a VCA instead of a summing stack? The key is how they handle sends. Let's say your drum tracks each have sends going to a reverb. If you pull down the fader on a summing stack, you're lowering the volume of the summed drum mix after the sends have already routed the signal to the reverb. The result is that your drums get quieter, but the reverb tail remains at its original level, making the mix sound washed out.

If you pull down a VCA Fader, it lowers the faders of the individual drum tracks themselves. This means less signal is sent to the reverb from each track. The balance between the dry drums and their reverb stays perfectly consistent, no matter where you set the group level.

Standard sidechain compression is a workhorse technique. You use the signal from one track (like a kick drum) to trigger a compressor on another track (like a bass), causing the bass to momentarily lower in volume—or "duck"—every time the kick hits. This creates space and prevents the low-end from getting muddy.

But what if you don't want the entire bass sound to duck? What if the bass has some interesting midrange texture you want to preserve? This is where frequency-specific sidechaining comes in.

Instead of a standard compressor, you can use a dynamic EQ or a multi-band compressor on your bass track. You set it up so that only a specific frequency range—say, everything below 200 Hz—is compressed when the sidechain signal from the kick is detected. The mids and highs of the bass remain completely untouched. This gives you a much more transparent and controlled way to carve out space in your mix.

To set this up in Logic, insert a multi-band compressor (like the Multipressor) on your bass track. Select the kick drum as the sidechain input source in the plugin's header. Then, bypass the mid and high bands of the compressor, and adjust the threshold and ratio of only the low band. Now, only the low-end of the bass will duck when the kick hits.

Mastering these routing techniques moves you beyond static mixing and into the world of dynamic, professional sound. By controlling how and when your signals interact, you can create mixes that are louder, punchier, and clearer.
