Conventional pulverized coal boilers have a persistent problem: ash. When low-quality coal with a high ash content is burned, mineral impurities melt and resolidify on critical components like superheater tubes. This buildup, called fouling, insulates the tubes, cripples heat transfer, and can force expensive shutdowns for cleaning.

The TRW multistage slagging combustor, developed for projects like Healy Unit 2 in Alaska, was engineered to solve this problem head-on. Instead of dealing with ash after it caused trouble, the system was designed to remove most of it before the hot gases ever reached the main boiler.

The system's first stage is a compact, water-cooled combustion chamber where pulverized coal is burned under substoichiometric conditions. This means there isn't enough oxygen to burn the fuel completely. The controlled, fuel-rich environment raises the temperature to around 3000°F, well above the melting point of the coal ash.

This intense heat turns the solid ash particles into a molten, glass-like liquid called slag. The combustor is designed to create a vortex, a powerful swirling flow of gas. This cyclonic motion acts like a centrifuge, flinging the heavier, liquid slag droplets to the chamber walls through inertial separation.

A layer of this molten slag coats the interior walls, insulating the chamber and protecting it from the extreme heat and corrosive atmosphere. As more slag accumulates, it flows down to a tap at the bottom of the chamber, draining into a water-filled quench pit. Here, the molten slag shatters into a safe, inert, sand-like material that is easy to handle and dispose of. This process captures up to 90% of the ash before it can cause any problems downstream.

The hot, fuel-rich gas exiting the primary stage still contains unburned fuel. This gas flows into the main furnace, or secondary stage, where additional combustion air is injected. With plenty of oxygen now available, combustion completes, releasing the remaining energy and heating the steam in the boiler tubes.

Because the vast majority of the ash has already been removed as slag, the gas entering the sensitive convective passes and superheater sections is clean. This drastically reduces fouling and fireside corrosion compared to a conventional dry-bottom boiler, where fine ash particles remain suspended in the flue gas.

This architectural difference allowed the TRW-Utility Demonstration Unit (UDU) design to effectively use waste coal and other low-grade fuels that would be disastrous in a standard boiler. The design converts a major liability, the ash, into a manageable byproduct before it can impact boiler efficiency and reliability.
